Mdr Branta Fish 19 W 230 V 36st Black

Mdr Branta Fish 19W 230V 36Deg Black – WOJP11366

LED luminaire BRANTA, with a power of 19 W, high light efficacy 135 lm/W. It is made of high-quality components, supported by a 5-year warranty. Narrow beam angle 36° gives directional light so that selected objects or surfaces can be better exposed. Designed to be mounted on a track.

Key specifications

• Power: 19 W
• Voltage: 230 V
• Nominal current: 90 mA
• Luminous flux: 1710 lm
• Lamp efficacy: 135 lm/W*
• Light color: CW
• Colour temperature: 5700 K
• Beam angle: 36 °
• Degree of protection (ip): IP20
• Dimension: 90x205x165 [mm]
• Warranty: 5-years
• Ra: 80
• Energy efficiency classe: E
• Assembly: na szynoprzewód 3-fazowy
• Housing colour: white
• Housing material: aluminum
• Dimmable: OPC

Selection and installation

Before installation, check the supply voltage, dimensions, mounting method and required IP rating. Select accessories and light sources according to this model’s technical documentation.
