LED module V-TAC 0,72W 3LED 160st SMD5050 IP67 VT-50503 6000K 66lm

V-TAC VT-50503 LED module for 6000 K backlighting

V-TAC VT-50503 is a compact LED module for illuminated projects where a small-format component and crisp cool-white light are needed. Its housing contains three SMD5050 LEDs. With a declared output of 66 lm, it works as one repeatable point in a larger lighting layout rather than as a standalone room luminaire. The 6000 K colour temperature creates a clear technical effect for illuminated letters, sign boxes and comparable display elements.

Key specifications

• Power: 0.72 W.
• 12 V supply.
• Three SMD5050 LEDs.
• Luminous flux: 66 lm.
• Colour temperature: 6000 K.
• Beam angle: 160°.
• Ingress protection: IP67.
• Dimensions: 67 × 15 × 8.5 mm.

Designed for sign projects

V-TAC describes this module for the signage industry. Its wide 160° beam can help distribute light across shallow backlit spaces, so the number and spacing of modules should be planned for the depth and material of the specific sign or box. Leads leaving both sides of the housing support the creation of 12 V module runs within a designed installation.

Protection in an appropriate installation

The IP67 rating describes the protected module housing, and the manufacturer states that the modules are suitable for mounting near water surfaces. It remains important to select the complete installation correctly: connections, wiring and the 12 V power arrangement must suit the actual mounting conditions and applicable safety requirements. The product carries a two-year manufacturer warranty. Choose this LED module when a cool-white, compact and repeatable light point is needed for a technical backlighting project.
