The 206S concrete foundation adapter is a Norlys part on which a garden luminaire or bollard from the manufacturer's list is mounted. On its product card Norlys classes it as a ground mounting anchor. It is made of hot-dip galvanised steel, coated with zinc by immersion rather than painted – which is why the index table gives no RAL number for 206GA0S10.
Construction and size
The adapter is a tube 108 mm in diameter and 490 mm long, closed at the top by a round Ø122 mm plate. Three M8×60 bolts stand out of the plate for bolting down the luminaire base, there is a Ø50 mm opening in the middle of the plate and a 25 mm wide slot in the tube wall. Overall it measures 12 × 12 × 49 cm, so the 49 cm length is the figure that matters when planning the foundation.
According to the manufacturer the adapter weighs 4.10 kg net and 4.30 kg in its 13 × 13 × 52 cm box.
Which luminaires it fits
The product card lists by index number the luminaires from the Alta, Arendal and Arendal Big, Astrid, Egersund Mini, Egersund Park, Frigga, Halmstad, Kisa, Lillesand, Lofoten (1966), Oppland and Stockholm families that mount on this adapter, plus the 3080 bollard adapter. Compatibility is decided by the index on that list, not by the family name alone, so compare it with your luminaire's index before ordering.
Luminaires are sold separately: the box holds only the mounting part, with no luminaire and no light source. Installation follows the instructions supplied with the product, which carries the CE mark.
