Mi-Light RF 2.4G 4 ZONE MONO B1 SURFACE PANEL

MiBOXER are products with a modern and modernistic design and an interesting and innovative way of working. The connection between the MONO receiver (sold separately) and the panel is made using radio waves at 2.4GHz. This means that the panel allows you to control MiBOXER products with a built-in receiver (e.g.. LED bulbs) and LED strips that are equipped with MiBOXER receivers. Surface panel powered by 3V batteries (2 x AAA)

4 independent zones can be specified on the panel, and any number of MiBoxer series receivers (sold separately) can be assigned to each zone. The possibilities for configuration are virtually endless.

Control of 4 zones using a single panel

Pairing the panel with the receiver is extremely easy. Perform the action of disconnecting the main power supply from the receiver (1), and then reconnect the power supply, where in the first 3 seconds briefly hold the previously selected channel on the remote control (2) respectively. The result of the correct pairing of the devices will be the blinking of the LED strip (3) three times.

Diagram of pairing the receiver with the panel

Functions: dimming, brightening, 4 zone, 60 second off switch

Dimensions 86x86x16mm Power supply 2xAAA (3V) Working range 30m Frequency 2.4 GHz Number of zones 4 Power consumption in standby mode 20uA Operating temperature -10 -40℃
