SLV NUMINOS ZOOM M DALI Track Spotlight white LED 20 W 780-1900 lm 4000 K 15-60° 3-circuit 1006119

NUMINOS ZOOM M DALI is a three-circuit track spotlight with a continuously adjustable beam from 15° to 60°, in white, rated 20 W at 4000 K and dimmable to the DALI standard.

Zoom – one spotlight instead of three

This is the feature the model is bought for. The beam angle is set mechanically on the fitting itself, anywhere from a narrow 15° to a wide 60°. In practice it means the optic does not have to be chosen at ordering time – and that is the commonest mistake in display-lighting design, because the angle is best judged on site, with the goods in place.

Output changes with the angle: from 780 lm at 15° to 1900 lm at 60°. That is not a fault but the physics of an adjustable optic – narrowing the beam works by cutting part of the flux, yet what remains falls on a smaller area and gives a far higher intensity at the centre of the pool. The narrow setting lifts a single object out of a dark background; the wide one lights a shelving unit or a sales zone evenly.

DALI control

The fitting dims to the DALI standard – a digital, addressable protocol. For a shop or gallery that is a meaningful difference from phase dimming: every fitting can be addressed individually, scenes can be built and changed without touching the wiring. It does require a DALI controller and a separate pair of control conductors, and that belongs in the installation stage, not after it.

Three-circuit track

The spotlight is made for three-circuit track in the EUTRAC (Eurostandard) format. Three circuits allow fittings on the same track to be split into independently switched groups – display and general lighting separately, for instance. The fitting does not fit single-circuit track or low-voltage magnetic systems.

The head is rotatable and tiltable, so after mounting the direction is set freely and changed with every new display.

4000 K and CRI 90

Neutral white 4000 K with CRI 90 colour rendering is the combination typical of retail and office space: the colours of goods look credible while the room turns neither yellow nor clinically cold. Glare index UGR ≤ 25, photobiological risk group 1, rated life 40,000 h.

Electrical data and build

Supply 220–240 V ~50/60 Hz, secondary current 500 mA, protection class I (earth conductor required). Permitted ambient temperature −20 to 40 °C.

The body is aluminium, in white, with a polycarbonate cover. Dimensions: 19 cm long, 16.5 cm high, head diameter 8.5 cm. Net weight 1.017 kg, gross 1.352 kg – worth totting up when planning a long run of track.

Specification

• Manufacturer: SLV, NUMINOS series, article no. 1006119
• EAN: 4024163261944
• Type: three-circuit track spotlight, rotatable and tiltable
• Beam adjustment: 15–60° (ZOOM)
• Power: 20 W
• Luminous flux: 780 lm (15°) to 1900 lm (60°)
• Colour temperature: 4000 K
• CRI: 90; UGR ≤ 25
• Rated life: 40,000 h
• Dimming: DALI
• Track system: three-circuit, Eurostandard EUTRAC
• Supply: 220–240 V ~50/60 Hz, secondary current 500 mA
• Protection class: I
• Ingress protection: IP20 (dry interiors)
• Ambient temperature: −20 to 40 °C
• Dimensions: length 19 cm, height 16.5 cm, diameter 8.5 cm
• Net weight: 1.017 kg; gross weight: 1.352 kg
• Materials: aluminium, polycarbonate cover
• Colour: white
