The V-TAC VT-60012RD-S is a round white LED panel designed for surface mounting. Its diameter is 167.4 mm and its height is 30.7 mm, so these dimensions should be compared with the available ceiling space before purchase. The integrated LED source draws 12 W and provides a luminous flux of 1200 lm.
This SKU 78751 version produces cool 6500 K light. A CRI rating of 80+ is specified, and the declared efficacy is 100 lm/W. The fitting operates on AC 220–240 V, 50/60 Hz; the manufacturer also states a nominal voltage of 230 V.
Construction and installation
The slim circular white plastic housing is for surface installation on a ceiling rather than recessing. It carries an IP20 protection rating. This is not evidence of moisture resistance, so it should not be used to select a fitting for locations that require higher protection.
The manufacturer specifies that this model is not dimmable. Because the LED source is integrated, the fitting does not use a replaceable screw-base bulb.
Specified uses
The manufacturer lists offices, conference rooms, showrooms, lobbies, booths and kitchens as example applications. The catalogue therefore assigns kitchen, office and shop use. The cool 6500 K colour temperature and 1200 lm output belong to this exact version, not to the other colour-temperature variants of the VT-60012RD-S range.
V-TAC declares a five-year warranty, more than 15,000 switching cycles and energy-efficiency class F. Installation conditions and compatibility with the local electrical installation should be checked before fitting.
