IR presence and dusk sensor QUATTRO HD KNX V3.1

Name: IR presence and dusk sensor QUATTRO HD KNX V3.1
Brand: STEINEL
SKU: 239473
Price: 356.13 EUR
Availability: OutOfStock

Code: 239473

Code Your affiliate link for this product

Share this link to earn commission from purchases.

Product code:

239473

Producer:

Manufacturer code:

ST079383

EAN:

4007841079383

Specifications

Angle of detection: 360 °
Brightness threshold sensitivity: 10-1000 lux
Condition: New
EAN: 4007841079383
Guarantee period: 5 years
Height: 10.8 cm
IP rating: IP20
View
Motion Sensors IP20
Length: 12 cm
Manufacturer code: ST079383
Mounting Options: Mounting: flush-mounted, ceiling, recommended mounting height: 2.8 m
Sensor: Motion and twilight
View
Motion Sensors With Motion And Twilight Sensor
Voltage type: 230 V
Width: 12 cm

Extremely wide detection zone of up to 400 m2 - The maximum detection range makes the sensor ideal for applications in offices, conference rooms, warehouses and sports halls.
Precision with 4800 switching zones - Dense detection grid provides exceptional sensitivity to motion and presence in medium to large size rooms.
Advanced integration with automation systems - Full compatibility with KNX bus and COM1, COM2 connections and Bluetooth IPD support allows for comprehensive building management.
Intelligent control and energy efficiency with IQ-mode - The sensor automatically adjusts its operating parameters according to room conditions, ensuring energy savings and occupant comfort.
Easy setup and quick ceiling installation - With a mobile app and dedicated Smart Remotes, RC6 KNX and RC7 KNX, device setup is quick and intuitive.

360° detection inlarge spaces - Excellent coverage in open and closed spaces such as lecture halls, open space offices and production halls.
Adjustable operating time from 10 seconds to 1092 minutes - Flexible settings allow you to fine-tune the unit's operation to meet your individual requirements.
Brightness level range of 2 - 1000 Lux - Ability to adjust sensor sensitivity to varying daylight levels.
Mounting height from 2.5 to 10 m - Ideal for high rooms where reliable presence detection is required.
Compatibility with additional accessories - Support for protective cages and various remote controls ensures easy expansion of functionality.

Device type: infrared presence detector (PIR)
Detection technology: 360°, 4800 switching zones
Detection angle: 360°, opening angle 160°
Detection range: up to 8 x 8 m (64 m2 presence), up to 20 x 20 m (400 m2 movement)
Mounting height: 2,5 - 10 m
Ambient brightness range: 2 - 1000 Lux
Operation time settings: 10 seconds - 1092 minutes
Power supply: KNX bus
Programmable outputs: 4x light control, HVAC, presence output, day/night functions, logic gate
Operating mode: IQ-mode, Bluetooth IPD
Current consumption: 10 mA
Interconnections: Master/Master, Master/Slave
Color: white (RAL 9010)
Housing material: plastic
Optional accessories: Smart Remote (EAN 4007841009151), RC6 KNX (EAN 4007841593018), RC7 KNX (EAN 4007841592912), protective cage (EAN 4007841003036)
Product code: 079383
EAN: 4007841079383
Warranty: 5 years
