Post-top luminaire head EGERSUND PARK Pro 6114 LED 23,7W 3000K DALI2 graphite RAL 7016 Norlys

The EGERSUND PARK Pro 6114 is the head of a post-top luminaire: a cylinder with a clear PMMA diffuser held between two rings of powder-coated cast aluminium in graphite (RAL 7016). The head itself is 120 mm in diameter and 66 cm tall, and it ends at the bottom in a spigot that slides into the pole.

What you get and what you need to buy separately

This is the luminaire only — no pole is included. Norlys sells the same head together with pole art. 6101 as the EGERSUND PARK Pro 6113 set, 250 cm tall overall; if you buy the head on its own, the pole has to be sourced separately. Mounting adapters 6132GA0009 and 6133GA0009 and the concrete anchor 6130XX0009 are also sold separately.

The head weighs 2.56 kg net, and the carton measures 14 × 14 × 78 cm and weighs 3.21 kg packed.

How much light it gives

The 20.5 W LED module produces 3363 lm, and 2239 lm leave the luminaire at a consumption of 23.7 W, which is 94.5 lm/W. That is enough light to illuminate a path or a small square rather than just mark a point. 3000 K is a warm white, and CRI 80 renders colours at the level usual for outdoor lighting.

The light is symmetrical and directed downwards. ULOR is 1%, so practically none of the output escapes above the luminaire — this matters near bedroom windows facing the garden and wherever sky glow over the site should be kept down. The manufacturer calculated the photometry for a mounting height of 2.5 m.

Control and servicing

The DALI outdoor driver supports DALI2 and NightDim. It leaves the factory programmed to maximum current, so without a controller the luminaire runs at full output; other settings are programmed by Norlys by arrangement with its sales department. Dimming therefore needs a DALI installation, not an ordinary phase dimmer.

The LED module and the driver are replaced by a professional service, using service kit ZS6114zx0009. The manufacturer states an LED lifetime of over 102,000 h at L80 and over 52,600 h at L90, and 100,000 h for the driver. The luminaire is rated IP65 and is intended for gardens, parks and the grounds of hotels and restaurants.
