Mantra HANOK 7549 linear module

Mantra HANOK 7549 Linear Module

HANOK is a white, recessed linear light designed by David Villalba. Its slim, straight aluminium-and-metal body ends in a black louvre anti-glare shield that screens the integrated LED source from direct view, cutting glare when working underneath the fixture.

Technical details

• Integrated LED source: 38 W, 2800 lm, 4000 K (neutral white), CRI 90
• Beam angle: 50°, not dimmable
• LED lifetime: approx. 50,000 h (approx. 46 years at 3 h/day)
• Supply: 220-240 V, protection class II
• Protection rating: IP20 – indoor use
• Connection cable: 1.5 m, silver colour
• Material: aluminium and metal
• Colour: white
• Dimensions: 120 cm length, 6.65 cm height, 4.8 cm depth
• Net weight: 2.2 kg
• Manufacturer warranty: 5 years

The compact cross-section (6.65 × 4.8 cm) and suitability for stretch ceilings let the fixture sit flush with the ceiling plane for a discreet line of light. The 120 cm length and even 2800 lm output suit corridors, kitchens, offices and other spaces where bright, glare-free task light is needed.
