NORLYS Molde DC1901CG LED garden bollard 80 cm, cement grey, 3000 K, 24 V DC

NORLYS Molde DC1901CG is an 80 cm LED garden bollard with a narrow upright body and a curved head projecting forwards. This cement grey RAL 7033 version combines a powder-coated cast-aluminium housing with a transparent, textured cover made from UV-stabilised polycarbonate.

Light beside paths and terraces

The head shields the diffuse light from above. Its construction suits lighting close to the bollard, including garden paths, terrace edges and passages around a property. The plain upright body, without decorative arms, works with modern and minimalist outdoor layouts. When choosing a position, compare the available space with both the base and the projecting head rather than considering the footprint alone.

Two LED modules have a combined power of 7.2 W and produce warm white light at 3000 K. The complete luminaire delivers 505 lm. The separate 1064 lm figure in the documentation describes the light sources, not the output leaving the finished fitting. Use the luminaire figure when comparing complete bollards or planning their placement. The spacing between lights should come from a lighting design, rather than from the height of the posts alone.

A separate 24 V supply is required

This variant operates on 24 V DC and needs an external constant-voltage power supply. It must not be connected directly to a 230 V mains supply. The LED modules support dimming, but the power supply and control arrangement must be selected as part of the installation design. Compatibility with an arbitrary existing wall dimmer should not be assumed. The manufacturer requires a suitably qualified person to select the supply and carry out the electrical installation.

Fixing and future servicing

The fitting measures 80 × 16.5 × 11 cm. Four fixing holes are 7 mm in diameter, with an 18 × 50 mm spacing. Mounting screws are not included; anchors and mounting adapters are purchased separately. The IP54 protection rating and IK07 impact rating apply to this outdoor fitting. Its LED sources are replaceable, but replacement is reserved for professional servicing rather than a routine user bulb change.
