SLV 143100 is a black, rigid straight connector with a feed-in facility for SLV 1~ SYSTEM surface-mounted single-circuit track. Its rectangular polycarbonate cover sits between two opposite connecting ends. This is a component of a lighting installation, rather than a luminaire or a power supply that converts voltage.
A straight joint that can receive the supply
The connector joins track sections in a straight line and provides the option of bringing power into the installation at that joint. It serves a different purpose from a corner connector or an end feed. When planning the track route, identify where the supply cable will reach the system. If that position is between two straight sections, the feed-in capability is the distinguishing feature of article 143100.
Use it with the specified SLV 230 V system. The manufacturer's instructions prohibit mixing the track and its components with parts from other track systems. A single-circuit designation on another manufacturer's rail is therefore not sufficient evidence of compatibility. Check the system family of the existing rails and accessories before ordering this connector.
Allow space for the connector body
The overall dimensions are 17.2 cm long, 3.5 cm wide and 1.8 cm high. Include that envelope when laying out the connection rather than assuming the joint has no visible body. The black cover matches the black accessory variant, and its plain rectangular form remains a technical part of the track installation. Article number 143100 identifies this finish within the connector family.
Installation and use
The manufacturer specifies a maximum current of 16 A. An approved electrician must select the installation load and carry out the electrical work with the supply disconnected. The track system requires a protective conductor, securely tightened connections and suitable caps on every open rail end. This connector does not replace those caps or the rails themselves. The instructions specify dry indoor use. External surfaces may be cleaned with a slightly damp cloth, but only after the complete system has been disconnected from the power supply.
