NORLYS Trelleborg 2607GR LED pole luminaire head graphite 3000 K

NORLYS Trelleborg 2607GR is a single pole luminaire head, not a complete garden light supplied with a pole. Its extruded aluminium body has a powder-coated graphite finish, RAL 7016. The angular profile, horizontal arm and underside optics give this series a modern, minimalist outline.

Choose the pole separately

The dimensions of 60.5 × 11 × 49 cm describe the head's length, width and height. They are not the overall height of the finished lighting point. Its mounting arrangement is intended for a pole with a 100 × 110 mm profile, so compatibility with the proposed structure needs checking before ordering.

The manufacturer lists Trelleborg poles in heights of 4, 5, 6 and 7 m as separately sold accessories. The pole and other accessories must be ordered separately. A photograph showing an assembled installation does not establish what is included with this head. Installation and servicing should be carried out by appropriately qualified personnel.

Light for outdoor spaces

The integrated LED module produces warm white light at 3000 K. The luminaire consumes 40.4 W and delivers 5538 lm; the LED source itself has a luminous flux of 5660 lm. A Ledil VSM lens provides IESNA Type V distribution. The intended uses include private outdoor areas and parks, with driveways or larger spaces beside a terrace also appropriate where a suitable pole is planned.

Use the photometric files to assess mounting height and spacing rather than relying on the lumen figure alone. IP65 and IK10 describe the enclosure's outdoor protection and impact resistance; the actual installation conditions still need checking.

Controls and future servicing

The driver supports DALI2 and NightDim. The manufacturer requires agreement with its sales department for programming further parameters, so establish the intended control arrangement before installation. The LED source and control equipment are replaceable by a professional service. This is not a fitting designed for routine replacement of a standard household bulb.
