SLV NUMINOS L CL DALI 1004603 Surface Ceiling Spot black LED 28 W 2700 K 36°

NUMINOS® L CL is a surface-mounted ceiling spot 10 cm across and 21.3 cm tall, in matt black. It needs no ceiling cut-out – it screws to the surface – and still has the optics and control of a recessed fitting.

DALI and Touch control

This is why you choose this variant over a cheaper one. The fitting supports DALI – the bus of specified installations, where every luminaire has an address and belongs to room-wide lighting scenes. The manufacturer lists a second technology alongside it: Touch, i.e. dimming from an ordinary push-button when there is no bus. The same fitting therefore works in an office with a control system and in a flat without one.

The light

A colour temperature of 2700 K is noticeably warmer than the 3000 K usual in spotlights – closer to incandescent than to retail light. The half-peak beam angle is 36°: moderately narrow, for building a grid of points over a display, a worktop or a seating area, not for lighting a room with one unit. Colour rendering of CRI 90 matters precisely because of that narrow angle – it decides whether the object lit keeps its colour. Distribution is symmetrical, emission direct, photobiological risk group 1. Rated life 50,000 hours.

Installation figures

Supply 200–240 V AC 50/60 Hz, protection class I (earth conductor required), IP20 – dry interiors only. Two numbers absent from domestic luminaire copy and decisive in a specification: inrush current 2.75 A for 190 µs, and a maximum of 94 luminaires on one circuit protected by a B16A or C16A breaker. Ambient temperature range: −20 to +50 °C. The LED module carries reference 1411536.

The NUMINOS system

NUMINOS is SLV's modular system of downlights and spotlights in several sizes and mounting versions – recessed, surface, pendant and track – sharing one appearance and one optical family. In practice that means recessed fittings can run where there is a suspended ceiling and surface ones where there is not, with a consistent lighting effect throughout.

Specification

• Manufacturer reference: 1004603, NUMINOS® L CL DALI
• EAN: 4024163247535
• Type: surface-mounted ceiling spot, integrated LED
• Power: 28 W
• Luminous flux: 2400 lm (85 lm/W)
• Colour temperature: 2700 K (warm)
• Colour rendering: CRI 90
• Half-peak beam angle: 36°
• Dimming: DALI, Touch
• Rated life: 50,000 h
• Dimensions: diameter 10 cm, height 21.3 cm
• Material: aluminium; plastic cover; colour: matt black
• Supply: 200–240 V AC 50/60 Hz, current 0.7 A
• Inrush current: 2.75 A / 190 µs; up to 94 luminaires per B16A or C16A circuit
• Ambient temperature: −20 to +50 °C
• Protection class: I
• Ingress protection: IP20 – dry interiors
• Weight net / gross: 1.044 kg / 1.335 kg
• Warranty: 5 years
