Nowodvorski CTLS 8712 PE-R right end feed, white, three-circuit

Nowodvorski 8712 is the white PE-R right-hand end feed for the CTLS three-circuit lighting track system. Its rectangular plastic housing covers the connection area, with copper listed by the manufacturer as an additional material. This component supplies power to the track: it is neither a light fitting nor a plain cap used only to close an open track end.

Choose the feed orientation before ordering

The RIGHT (PE-R) designation matters when assembling the track layout. The CTLS manual distinguishes right-hand feeds, left-hand feeds and separate dead end caps. It also marks system polarity with a red line and instructs the installer to observe the earth contact. Check the orientation of the track end against the system drawing rather than selecting a connector by colour alone.

The package contains the end feed. Tracks and light fittings are separate system components, so this item is not a complete lighting kit. Compatibility should be established with the CTLS system; a similar-looking rail is not sufficient evidence that another system will accept it.

Allow for the connection at the track end

Overall length is 10 cm, with both width and height measuring 3.2 cm. The manufacturer also specifies a 3.6 cm section within the track, a useful distinction when planning the end of a run. The white housing can be coordinated with white CTLS components. Its plain, undecorated shape remains a technical connection detail rather than a decorative light source in its own right.

Indoor electrical installation

The feed is intended for indoor use and is also recommended by the manufacturer for the hospitality sector. The stated connection ratings are 16 A and 3.7 kVA at 220–230 V AC, 50/60 Hz. These are not light-output figures or the consumption of an individual lamp. Electrical protection class I requires an earth connection. A qualified electrician must install and connect the component in accordance with the CTLS instructions, with the supply isolated.
