LUMINES DOUBLE opal PMMA LED profile diffuser, 2 m Special Offer

The LUMINES DOUBLE opal PMMA diffuser is a cover for compatible LED profiles. Variant 11-2071-20 has a nominal length of 2 m. Its flat white face screens the profile interior and diffuses light from the LED strip. This is not a transparent cover or a complete light fitting.

Transmission for this material and shape

The current LUMINES datasheet gives DOUBLE in opal PMMA a light transmission of 42%, with a test-result tolerance of ±5%. This figure belongs to this particular combination of cover shape and material, rather than every opal diffuser in the range. Allow for the light lost through the cover when selecting a strip: the strip's own lumen rating is not the output of the assembled fitting. The diffuser does not determine the installation's colour temperature or electrical power.

Match the profile designation

The manufacturer lists compatibility with HIRO, PLATO, SILEDA, inSILEDA, DILEDA, inDILEDA, UNICO, DOPIO, TALIA, inTALIA, ZATI, SUBLI, LOGI, CONVA, TOPO, PERO, VEDA, MOTTA, DULIO, FIXO and GEMI. Compare your profile's designation with this list before ordering; matching the length alone is not enough. DOUBLE identifies the cover family, not one individual profile system.

The stated operating-temperature range for the material is -20°C to +70°C. This is not an IP rating for the complete installation. Where water exposure is relevant, check the documentation for the assembled system.
