Steinel Multisensor True Presence TP V2 IP UP WS sensor

True Presence Multisensor — real presence detection

Steinel True Presence is a ceiling sensor that detects a person by their breathing rather than their movement — its 7.2 GHz high-frequency technology means the light does not switch off when someone sits still at a desk. Alongside presence it measures brightness, temperature, humidity, air pressure, CO2, VOC and noise level.

Specification

• Power over Ethernet: passive PoE SELV and standard PoE (IEEE 802.3af)
• 1 W power consumption, bus coupling, configured via Bluetooth Mesh and a web interface
• 360° detection angle, reach Ø 15 m (177 m²); true presence Ø 9 m (64 m²)
• Mounting height 2-12 m (2.8 m optimum); max 4 m for true presence
• Detects through glass, wood and stud walls
• Twilight setting 2-2000 lx, ambient temperature 0-50°C, IP20
• 123 x 123 x 53 mm, plastic, white (RAL 9003), concealed ceiling installation
• 5-year manufacturer's warranty
