Motion and twilight sensor IS 345-R KNX V3.1 DE

Steinel IS 345 KNX V3 Ceiling Presence Sensor IP20 White Round Product Code 079703.

Benefits of the IS 345 KNX V3 sensor in building automation

• Effective monitoring in heavily used spaces - Detection range of 23 x 6 m (tangential) and 12 x 6 m (radial) provides excellent coverage in passageways, corridors and public spaces.
• Ideal ceiling mounting up to 5 meters high - Designed for installation in suspended ceilings, it guarantees high detection efficiency in spaces with great height.
• Full KNX compatibility - Enables comprehensive control of lighting, HVAC, brightness level and building automation logic, integrating with other elements of smart installations.
• Energy Saving and Convenience - Adjustable light level (0-100%), TEACH function for twilight settings and low power consumption optimize operating costs.
• Simple configuration and intuitive operation - Easy programming using the Smart Remote or RC6 KNX and RC7 KNX remotes makes it easy to customize the device to individual requirements.

Functions and applications of the IS 345 KNX V3 sensor

• 360° detection for complete space control - Perfect for offices, corridors, entrance areas and high traffic areas.
• Programmable run time from 0 s to 1092 minutes - Flexible settings allow you to fine-tune the sensor's run time to meet the needs of your space.
• Creep protection - The protection function eliminates detection blind spots, increasing the sensor's effectiveness.
• Elegant white design in RAL 9003 - The round design fits perfectly into modern office and commercial interior designs.
• Resistance to harsh operating conditions - IP20 protection class and an operating temperature range of -20°C to +50°C ensure reliability in a variety of environments.

Technical and logistical data of the product

• Device type: infrared motion sensor (PIR) with light sensor
• Detection technology: passive infrared + light sensor
• Detection angle: 360°
• Detection range: tangential 23 x 6 m (138 m2), radial 12 x 6 m (72 m2)
• Mounting height: 2,5 - 5 m
• Ambient brightness range: 2 - 1000 Lux
• Operation time settings: 0 seconds - 1092 minutes
• Protection class: IP20
• Operating temperature: -20°C to +50°C
• Color: RAL 9003 (white)
• Housing material: plastic
• Power supply: KNX bus
• Connection type: Master/Slave
• Power consumption: < 1 mW
• Rated current: 12.5 mA
• KNX functions: photocell controller, basic light level, light level, HVAC output, constant light control, 2x light output, presence output, day/night function, logic gate
• Optional accessories: Smart Remote (EAN 4007841009151), RC6 KNX (EAN 4007841593018), RC7 KNX (EAN 4007841592912), black sensor cover (EAN 4007841056742)
• Product code: 079703
• EAN: 4007841079703
• Warranty: 5 years
