STEINEL IS 3360 MX Highbay DALI-2 IPD Motion Detector, Surface-Mounted Square 057374

STEINEL IS 3360 MX Highbay DALI-2 IPD

The square, surface-mounted STEINEL IS 3360 MX Highbay is a motion detector developed for lighting automation at considerable mounting heights. Article 057374 is a DALI-2 IPD input device: it passes detection data to a higher-level lighting-management system rather than switching a luminaire on its own. This makes it a precise component for installations where addressed bus devices and dependable occupancy data are required.

Coverage for high-bay spaces

Its 360° passive-infrared sensor is designed for ceiling mounting from 4 to 14 m, with 12 m identified by the manufacturer as the optimum height. The tangential reach is Ø 36 m, covering up to 1,018 m². That scale suits a high-bay warehouse, sports hall or commercial interior where a single ceiling position must observe a broad area. Supplied shrouds allow individual detection segments to be masked when the monitored zone needs refining.

Installation facts

• DALI-2 Input Device IPD with communication via the DALI bus;
• square surface installation; housing dimensions 95 × 95 × 65 mm;
• 360° detection angle and twilight setting from 2 to 1,000 lx;
• UV-resistant plastic housing, IP54, operating temperature −20 to +50°C;
• DALI-bus supply of 12–22.5 V and up to three DALI users.

Designed for professional control systems

The IS 3360 MX Highbay belongs in centrally managed lighting projects, not in a standalone switched circuit. Its white housing includes a generous terminal compartment and is intended for ceiling installation. In warehouses, production areas and sports facilities, its long reach helps provide sensor data where conventional room-scale detectors would be insufficient. The final addressing and system setup should be carried out by an installer familiar with the DALI bus.
