LUMINES profile type FLEXA white lacquered 2 m

Specialized LED profile for surface mounting, designed to bend in both planes. Enables the creation of continuous, curved lines of light that precisely match the geometry of architectural forms, without degrading the mechanical, optical or aesthetic performance of the luminaire. The system provides for the use of connectors and overhead mounting, which ensures high configuration flexibility and easy integration into different types of spaces.

Table of minimum bending radii of LUMINES profiles

Type of bending Direction of illumination (position of the lampshade in the luminaire) FLEX diffuser PMMA/PC diffuser horizontal (transverse) downward 475 - vertical inward 360 360 vertical (upright) outward 175 250

Minimum bending radii in mm for a given lampshade. The maximum diameter of the circle is 1850 mm (from a 6 m profile).
Tolerance: +/- 5%. Technology tips: 250 mm. The bent profiles are available in lacquered version only.
Bending service available by contacting the service office in advance.
